The Break Away Connector (BAC) is designed to address drive-offs during tanker trucks/tank trucks loading and unloading operations. To ensure safe product transfer, the grounding clamp must always be attached to the tanker truck before any other operations begin and securely stowed after all activities are completed. Failure to follow this procedure can result in the tanker truck driving off with part of the grounding system, causing costly damage and lengthy delays in restoring the safety system. The BAC mitigates this risk by allowing the grounding clamp and one-half of the connector to separate from the cable if a drive-off occurs, meaning only the clamp and connector need to be replaced to quickly restore the grounding system.

The Universal Resistance Tester (URT) is designed to provide users of Newson Gale Bond-Rite^® static grounding systems with a means of testing the permissive resistance range on a regular basis.

The easy-to-use tester consists of a pair of rotary switches that enable a competent electrical person to check the resistance level at which the grounding system should be working and conduct a PASS/FAIL test at the required setting.

The Earth-Rite^® II MGV Tester is a capacitance resistance tester (CRT) designed to have the same electrical characteristics as a tanker truck and provides engineers with a means of checking that the Earth-Rite^® II MGV undergoing installation is permissive when it detects these characteristics.

The tester is connected to the Earth-Rite^® II MGV system and its grounding point, and when activated, the Earth-Rite^® II MGV’s LED indicators change from red to green, confirming that the Tanker Truck Recognition and Static Ground Verification checks are functioning as intended.

The CRT is highly recommended with a minimum of one per site.

• Required for system commissioning and routine service checks
• Easy to use with simple PASS/FAIL condition

Newson Gale’s R-series of static grounding reels offer Hytrel^® cable housed on automatically retractable cable reel.

An optional stowage point is available for the VESX50-IP 2 pole magnetic grounding clamp. It allows the clamp to have a designated stowage point close to the item of ferrous metal based plant that the operator can use to stow the clamp safely when it is not in use.

Cen-Stat™ is a range of brightly coloured cables specially designed for applications in industrial and hazardous locations. Cen-Stat™ cables are based upon Hytrel^® that combines the flexibility of rubber with the strength and process flexibility of thermoplastics.

Cables made from Hytrel^® are mechanically resilient, have a wide working temperature and are resistant to a wide range of chemicals, as well as strong and durable.

The Cen-Stat™ range of FM and ATEX approved static grounding clamps and systems are designed to operate in the harshest hazardous locations. The certifications achieved by our range of clamps and cables benchmark their ability to establish and maintain good electrical contact with equipment requiring static grounding and bonding protection.

• Grounding and bonding metal objects ranging from small cans to 55 gallon drums.
• Stainless Steel 304 construction body.
• Strongest type of commercial Neodymium magnets.
• Quick connect functionality for easy removal out of hazardous location.
• Monitors to 10 ohms or less.
• Can be integrated into the Earth-Rite^® and Bond-Rite^® systems to ensure a true verified ground connection.

• Grounding and bonding metal objects ranging from 55-gallon drums to large metal totes and IBCs.
• Stainless steel 304 construction body.
• Tungsten carbide teeth to bite through paint deposit buildup.
• Quick connect functionality for easy removal out of hazardous locations.
• Monitors to 10 ohms or less.
• Can be integrated into the Earth-Rite^® and Bond-Rite^® systems to ensure a true verified ground connection.

• Grounding and bonding metal objects ranging from small cans to 55-gallon drums.
• Stainless steel 304 construction body.
• Tungsten carbide teeth to bite through paint deposit buildup.
• Quick connect functionality for easy removal out of hazardous locations.
• Monitors to 10 ohms or less.
• Can be integrated into the Earth-Rite^® and Bond-Rite^® systems to ensure a true verified ground connection.

Equipment specifiers can order the Bond-Rite^® CLAMP with 2-pole Cen-Stat^TM cable on standard spiral lengths of 10 ft (3 m), 16 ft (5 m),  32 ft (10 m) and 50 ft (15 m) of cable.

The spiral cable retracts when the clamp is not in use, ensuring the cable is neatly stowed and safely out of the way.

The Universal Resistance Tester (URT) is designed to provide users of Newson Gale Earth-Rite^® static grounding systems with a means of testing the permissive resistance range on a regular basis.

The easy to use tester consists of a pair of rotary switches that enable a competent electrical person to check the resistance level at which the grounding system should be working and conduct a PASS/FAIL test at the required setting.

With this assembly operators tasked with grounding mobile process equipment will have a dedicated grounding point to attach the easy-to-use screw thread connector. The ‘plug-and-play connector can interface with all Newson Gale 2-core systems to provide ground monitoring capability on a wide range of mobile processes and equipment where generic grounding clamps cannot be used. The conical shape design aids in the reduction of powder deposit buildup over time and aids in clean-down operations.

• Made using stainless steel with Viton O-Rings
• IP 66
• -40° F to 140˚ F (-40° C to 60° C)
• Various lengths of straight or spiral Hytrel^® cable available.

A quick and easy-to-use grounding kit that may be swiftly deployed in an emergency or combustible material transfer operations where pre-existing designated grounding points are not available or accessible.

The portable grounding kit combines multiple shortened grounding rods (14 inches long) with surface wire grounding techniques to provide acceptably low resistance for static grounding requirements in field operations.

The flexible array of interconnected grounding rods is inserted into the soil at specified intervals to maximize the ability to safely dissipate static electricity from mobile trucks, service vehicles, and other equipment.

• Kit includes multiple rods, surface grounding wires, ground tab and driver tool.
• Quick and easy to install and retrieve.

Static Grounding Canvas Kit Bag for Portable Grounding Kit and Cen-Stat™ Clamps, Assemblies, and Tools.

The strobe light is mounted in an elevated position and when the equipment is correctly grounded, flashes continuously informing personnel that a transfer process is underway and is protected from the static hazard. The strobe light can be used in conjunction with this product.

Designed for operating environments subject to intense sunlight, the ERII Sun Shield protects against direct sunlight hitting the indicators on the static grounding system.

The Sun Shield casts a shadow over the indicators during peak sunlight hours so that operators can easily view the ground status indicators. The shield is constructed from stainless steel and can be fitted to any installation in a matter of minutes.

The IS Switching PCB is an additional circuit board added to Newson Gale system enclosures, enabling users to directly interface with, and switch, intrinsically safe circuits without the need for additional equipment. The IS Switching PCB is designed not to affect the IS signal’s electrical parameters and is compatible with this product.

• Suitable for Ex ia, ib, and ic rated intrinsically safe circuits only

The retractable cable reel is supplied for grounding system installations where customers want to ensure the grounding clamp and cable are returned to the static grounding system by operators and drivers on completion of the material transfer process. The reel can be used in conjunction with this product.

The Earth-Rite^® II RTR Tester is a capacitance resistance tester (CRT) designed to have the same electrical characteristics as a tanker truck/tank truck and provides engineers with a means of checking that the Earth-Rite^® II RTR undergoing installation is permissive when it detects these characteristics.

The tester is connected to the Earth-Rite^® II RTR system and its grounding point, and when activated, the Earth-Rite^® II RTR’s LED indicators change from red to green, confirming that the Tanker Truck Recognition and Static Ground Verification checks are functioning as intended.

The CRT is highly recommended with a minimum of one per site.

• Required for system commissioning and routine service checks
• Easy to use with a simple PASS/FAIL condition
